Meet Bedrock xt2
Meet Bedrock XT2: the foundation of your adventures
The result of an epic collaboration between KRUG EXPEDITION and Arctic Trucks is a unique expedition grade truck especially made for the US.
Arctic Trucks are on the forefront of polar transportation, and KRUG brings over a decade of experience in building expedition grade trucks and 230+ finished projects to the table. BEDROCK XT2 is a one of a kind 6x4 off-road machine converting a luxury variant of the Ford Super Duty F-550 and bringing it to the next level with suspension and chassis frame reliability.
Make great presentations, longreads, and landing pages, as well as photo stories, blogs, lookbooks, and all other kinds of content oriented projects.
An additional tag rear axle decreases the ground pressure by upwards of 25%, while formidable 365/80R20 Continental MPT tires provide superb traction in rugged terrain and smooth operation while driving on the road.
The three axle design solves a common issue of overloading the rear axle, with BEDROCK XT2 load distribution is perfectly balanced, greatly improves breakover and departure angles and allows for a longer living habitat without compromising the off-road performance of the truck. The new rear tag axle also features hydraulic disc brakes for improved control and reduced braking distances.
For even greater convenience, Arctic Trucks' 8-link rear air suspension system includes independent control from inside the cab, allowing quick air pressure adjustments to accommodate varying payloads and terrain.
Details
176 in
10-speed automatic
Arctic Trucks AT44 XT2 Ford F-550
POWERSTROKE 6.7L V-8 DIESEL, 330 HP
85 gal
Super Cab
BASE VEHICLE
Chassis
Wheelbase
Gearbox
Cab
Engine
Fuel tank
External dimensions
LIVING MODULE:
01
01
02
03
Height: 148 in.
02
Width: 98 in.
03
Length: 330 in.
The interior of the living module is modern and appealing.
The design emphasizes function and tailored to the needs of long-distance travelers. There is a wide range of materials to choose from, allowing you to customize your module according to your taste.
MODULE INTERIOR
Furniture made from lightweight wood panels
Safety locks on the furniture doors and drawers
Visible surfaces covered with decorative HPL or wooden veneer
Dinette with high-quality fabric upholstery or leather upholstery
Stainless steel sink by Blanco with scratch resistant coating
Oven with Microwave by Miele
Vitrifrigo C270DP fridge-freezer combination:
Refrigerator compartment volume: 169 L (44.65 gal.)
Freezer compartment volume: 57 L (15 gal.)
01
02
03
04
05
01
02
03
Induction hob by Mile, with two cooking zones
Fenix NTM soft touch anti-fingerprint worktop
Stainless steel sink by Blanco with scratch resistant coating
04
05
Vitrifrigo C270DP fridge-freezer combination
Oven with Microwave by Miele
Vitrifrigo C270DP fridge-freezer combination:
Refrigerator compartment volume: 169 L (44.65 gal.)
Freezer compartment volume: 57 L (15 gal.)
Foldable worktop extension
06
06
Foldable worktop extension
Dinette with high-quality fabric upholstery
The table in the dining area can be easily converted into additional sleeping
01
02
03
01
02
03
The table in the dining area can be easily converted into additional sleeping
Dinette with high-quality fabric upholstery
Vitrifrigo C270DP fridge-freezer combination
Vitrifrigo C270DP fridge-freezer combination:
Refrigerator compartment volume: 169 L (44.65 gal.)
Freezer compartment volume: 57 L (15 gal.)
Vitrifrigo C270DP fridge-freezer combination:
Refrigerator compartment volume: 169 L (44.65 gal.)
Freezer compartment volume: 57 L (15 gal.)
Roof hatch made of insulated sandwich panels, including insect screen and warning buzzer
King Size Bed ( 76 IN x 80 IN) in cabover part of the module
01
02
01
King Size Bed ( 76 IN x 80 IN) in cabover part of the module
02
Roof hatch made of insulated sandwich panels, including insect screen and warning buzzer
Mirror
Waterless Separate Tiny dry separation toilet with 7.5 L (2 gal.) urine tank (Ceramic gravity toilet is optional)
Shower with shower set and concealed underfloor shower tray
Built-in GRP sink with single-handle faucet
Cabinet for bathroom accessories
01
02
03
04
05
01
02
03
Mirror
Cabinet for bathroom accessories
Built-in GRP sink with single-handle faucet
04
05
Waterless Separate Tiny dry separation toilet with 7.5 L (2 gal.) urine tank (Ceramic gravity toilet is optional)
Shower with shower set and concealed underfloor shower tray
Technical Features
Krug XP Bedrock Module
118
Gallons of fresh water
60
Gallons CAPACITY GREY WATER
1 450
Watts of solar power
23 000
Watt hourS lithium ion battery bank
Technical Features
COMPOSITE TECHNOLOGY
MODULE BODY
KRUG EXPEDITION builds their module walls using reinforced sandwich panels with superior insulation and performance characteristics. Each living habitat is completely free of cold bridges. This prevents accumulation of condensation inside the module, and also means a significant overall decrease of energy consumption in extreme cold and hot environments.
Both the inside and outside of the wall and ceiling panels are coated with an extremely strong GRP laminate. Due to its very high fiberglass percentage, 70%, and its cross-woven structure, the outer GRP laminate is extraordinarily resistant to mechanical influences. This is one of the major quality features that distinguishes us from our competitors.
By default, all our modules are equipped with a diesel-powered air heating system, which offers very short heat-up times, low-noise operation and infinitely variable power control for a consistent temperature inside the module.
The fresh water tank is filled via the filler neck in the side wall of the module, enabling to fill the tank when the water pressure is insufficient or there is a need to fill from the canister. The system for pressurized filling, includes water pre-filtration and a powerful UV treatment unit. The fresh water is pre-filtered via a filtration system with 3 pre-filtering stages with activated carbon and a fine filter capacity of up to one micron. The water is then treated with PURION 1000 UV lamp. The UV lamp emits a wavelength of 254 nm without producing any ozone.
Our modules and their equipment are designed to provide a fully electric experience. Powerful solar panels, a generously sized battery bank and matching components by Victron (an established manufacturer of energy systems for marine and off-grid applications) ensure a reliable supply of energy wherever you may be, so that you don’t have to worry about procuring gas bottles and / or adapters. With our system you are not limited to 120V power supply, but can also charge from 230V, which makes it possible to charge anywhere in the world.
Make great presentations, longreads, and landing pages, as well as photo stories, blogs, lookbooks, and all other kinds of content oriented projects.
This wavelength ensures that germs, bacteria, viruses and spores are eliminated. The PURION 1000 enables you to disinfect drinking water at a flow rate of up to 1,000 l/h (265 gal./h). The water supply is realized by means of two pressure pumps, which can be switched independently of each other. This makes our water supply system fail-safe and redundant. Fresh water going to the drinking water tap in the kitchen is additionally filtrated with General Ecology Seagull IV-X2 system with carbon activated pre-filter that ensures the effective removal of chemical and visible contaminants, including herbicides, pesticides, chlorine and other particles exceeding 0.4 micron (4 nanometres). Furthermore, the filter removes bad taste, odours and turbidity.
The next layer of drinking water treatment is UV LED unit. Its purpose is to eliminate any residual bacteria or viruses that were not filtered out in the previous stages. UV LED disinfection unit is fully automatic. It has no warm-up phase, unlike traditional UV lamps, and turns on instantly when the water is being drawn. External shower outlet is on the right side of the module in the garage compartment. Cold and hot water supply circuits feature compressed air inlets allowing to blow the residual water out of the system when preparing the module for winter storage.
Fresh water tank - 450 L (118 Gal.)
Grey water tank - 225 L (60 Gal.)
Black water tank - 65 L (17 Gal.) - comes with Macerator Toilet option
All tanks are located inside the module and are equipped with an automatic frost protection system. The fill levels of the tanks are monitored by level sensors and displayed on the central control panel inside the living module. The grey tank is emptied by means of electric control switch located in the garage compartment or manually in case of an emergency.
Content Oriented Web
Make great presentations, longreads, and landing pages, as well as photo stories, blogs, lookbooks, and all other kinds of content oriented projects.
Since the mechanical stress placed on the interior is significantly lower, we use a GRP laminate with a lower fiberglass concentration compared to the GRP laminate which is used on the outside. This saves a significant amount of weight and enables the possibility to add an extra thick gelcoat layer that covers the laminate surface, resulting in a perfectly smooth interior finish.
Thanks to the excellent thermal insulation properties of the polyurethane foam which is used between the two laminate layers, our 2.36 inch panels offer the same level of insulation as a solid wood wall with a thickness of approximately 11.8 inches.
WHAT ELSE IS INCLUDED:
Interior walls and doors in accordance with the layout
Complete interior and exterior painting in the color of your choice
6x fold-out windows made of tempered safety glass with double insulation and UV protection coating
Insect and sun protection / black out roller blinds on the windows
Laterally sliding insect screen on the entrance door
Storage space in the rear part of the module with a full slide-out platform
Roof hatch made of insulated sandwich panels, including insect protection and warning buzzer
Marker lights in the rear and on the sides
Powerful external LED scene lights on the right and left side as well as on the rear of the module
Set of cargo boxes under the module
Robust retractable electric stairs under the entrance door
Spare tire carrier with sand boards holder and additional cargo boxes
Metal brush guards on the rood and cabover part of the module
Content Oriented Web
Make great presentations, longreads, and landing pages, as well as photo stories, blogs, lookbooks, and all other kinds of content oriented projects.
High Energy lithium-ion battery bank by Victron
Very high energy density (very high energy content with low weight)
Integrated battery management system
Very high safety standard
12 V, 1980 Ah total capacity (23.7 kW/hours)
Used for provide power for the kitchen appliances and charge the batteries outside North America
Inverter power: 5000 VA (4000 W cont. output, 10000 W peak power)
Charging capacity: 120 A
Standardized energy supply Powerbox
Victron Quattro 5000 230V Inverter and charger
Victron Quattro 5000 120V Inverter and charger
Used for feeding the power into the power sockets and charge the batteries in North America
Inverter power: 5000 VA (4000 W cont. output, 10000 W peak power)
Charging capacity: 120 A
1450 Wp of solar panels
DC / DC charge controller (12 V / 50 A) for charging the module batteries from the vehicle's alternator
Emergency start feature for starting the vehicle using the module batteries
Fuse panel with automatic circuit breakers and residual current operated circuit breakers
Victron color control monitor and wireless remote system monitoring
Worldwide monitoring of the system via VictronConnect app
Dimmable, recessed ceiling-mounted LED luminaires
Dimmable, separately adjustable LED light strips underneath the wall units
Dimmable reading lights in the bedroom and dining area
11 x 120 V sockets
5 x USB-C charging ports
3x12Vsocket
Interior lighting and sockets
120 V socket on right side of the garage compartment
120 V shoreline power connection, 32 A, high-quality charging cable
Exterior LED lights on all 3 sides of the living module (left, right and rear)
Marker lights
Outdoor lighting and sockets
Preparation for Starlink installation
32" Smart TV in the dinette area
24" Smart TV in the cabover section
Additionally included
Content Oriented Web
Make great presentations, longreads, and landing pages, as well as photo stories, blogs, lookbooks, and all other kinds of content oriented projects.
Air Heating
Truma Combi D6 E air and water heater
2x powerful Maxxair roof ventilators in the living area and bathroom
Hot air (heating capacity of up to 6 kW) and hot water (up to 60°C / 158°F) in 11L (3 Gallon) water boiler
Anti-freeze mode, frost-protection feature and infinitely variable temperature control
Infinitely variable, low-noise and fuel-saving fan and burner operation
Temperature adjustment and display of actual values via a digital control panel
Efficient performance at altitudes of up to 2,750 meters (9000 ft)
Air inlet and outlet modes
Remote-controlled
Air-conditioning features
Rain sensor that closes the hood automatically upon detection of rain • Additional proprietary insulating hood on the roof of the module that prevents condensation in low outside temperatures
Ventilation
OPTIONS & ADD-ONS
BASE VEHICLE
OPTIONS
-----Central Tire Inflation System When driving an off-road truck in difficult conditions, the tire air pressure is critical to achieving optimal performance. Drivers must be able to evaluate the surface and find the right pressure in the tires to suit the situation. The pressure settings off-road are heavily dependent on the terrain, vehicle, and payload – with our Central tire inflation system (CTIS), dynamic adjustments to the tire pressure can be made on the fly, allowing the truck to quickly adapt to the terrain.
-----Webasto auxiliary diesel heater
MODULE INTERIOR
OPTIONS
-----Wood veneer furniture surface Individual selection from our pre-selected natural wood furniture surfaces according to your preferences.
-----Leather upholstery for dinette cushions Individual selection from our pre-selected leather range surfaces according to your preferences.
-----Panorama roof hatch glazing Double glass insert in the roof hatch. Including an internal insect screen and sun protection / black-out blinds.
COMFORT
OPTIONS
-----Nespresso coffeemaker Installed above kitchen in a stainless tray.
-----Washing machine with dryer Resistant to vibrations, this washing machine is mounted inside the module and connected to the energy and water supply system as well as to the grey water tank
-----Macerator toilet and black water tank Yacht-quality macerating toilet by Tecma. Black water tank (17 gal.) with external ventilation via an activated carbon filter and an irrigation pump that pumps the water from the grey water tank into the black water tank for flushing purposes. If required, this feature also makes it possible to increase the available grey water tank volume. Instead of Separett Toilett, surcharge.
HEATING AND AIR CONDITIONING
OPTIONS
-----Advanced Liquid Heating System (5 kW) A highly efficient liquid-based heating system with underfloor heating, radiators, including towel radiators, and the water boiler. We employ high-quality pipe systems used in house construction.
A liquid heating system enables you to use an underfloor heating system, while also keeping the module warm for longer due to the extended heat emission from the heating pipes, the radiators, as well as the floor, that has absorbed the heat. The primary heat source of the system is a 5kW Webasto diesel heater. The system is also connected to the truck’s engine heat transfer circuit through a heat exchanger.
-----Starlink installation Installation of a Starlink system provided by the customer
ADD-ONS
OPTIONS
-----Lightweight hydraulic bike lift Carrier for e.g. 1 motorcycle and 1 complete spare wheel OR for 2 complete spare wheels. Max. payload 500 kg. Mounted on the subframe, galvanized and powder-coated.
-----Outdoor kitchen External stainless steel pull-out kitchen with 2 fold outs for installation in an underfloor storage box, Kenyon electric grill and a sink, electrical connection, water supply via external shower from the rear garage compartment to prevent frost damage, water drainage to the outside via a long hose.
*late release
ACCESSORIES
OPTIONS
-----Submersible water filling pump High performance submersible pump for filling freshwater tanks from unpressurised sources or natural freshwater bodies.
-----Complete set of cutlery, tableware and cookware
Tefal Cooking pot set (3x)
Tefal Pan set (2x)
Tefal lid set (3x)
Medium wine glasses (6x)
Short wine glasses (6x)
Villeroy & Boch espresso cups (4x)
Villeroy & Boch coffee mugs (4x)
Villeroy & Boch saucers (4x)
Villeroy & Boch medium plates (6x)
Villeroy & Boch large plates (6x)
WMF Cutlery set
WMF Knife set
Content Oriented Web
Make great presentations, longreads, and landing pages, as well as photo stories, blogs, lookbooks, and all other kinds of content oriented projects.
This solution provides a redundant heat source when the engine is running, which in the opposite direction also enables the engine to be preheated with the help of the Webasto diesel heater.
An additional electric heating element in the boiler, which draws the energy from the batteries charged via solar energy or from shore power, provides an additional energy source for hot water generation. It is easy to switch between the various energy sources. All of these benefits make for a system that is very flexible and far more efficient and suitable for cold regions than conventional air heating systems.
Underfloor heating in the living area
Radiator in the dinette
Radiator in the sleeping area
Towel radiator in the bathroom
Radiator in the garage compartment
Heat exchanger connected to the vehicle engine
Possibility to preheat the vehicle engine
Automatic frost protection
This extraordinarily compact roof-mounted air conditioner is designed to offer the highest possible efficiency and lowest possible energy consumption. Easy to operate, with flexible air flow thanks to independently rotating diffusers which can be adjusted effortlessly, either via the integrated control panel or remote control.
Nomadic Cooling X3 Air Conditioner
Rated Cooling Capacity (BTU): 11,830
Extraordinarily low profile external unit
Get in touch to receive all relevant information on BEDROCK XT2 — we are looking forward to connect!
